Battery Safe Containers

Certified containment for thermal runaway up to 20kWh

Battery Safe containers provide a secure, certified solution for storing, transporting and handling lithium-ion batteries. Designed and manufactured in the UK, and independently tested to UN standards for transportation, they offer proven protection for ALL TYPES of batteries, at ALL STAGES.

Independently tested and certified:

UN Chapter 6.1 for dangerous goods transport
UN LP906 (damaged, defective and prototype batteries)
ADR – road transport
RID – rail transport
IMDG Code – maritime transport

Find out more

Performance & Certifications

Performance criteria met:

External temperature remains below 100°C
No flames escape
No projectiles escape
Structural integrity maintained throughout the event
Gas management prevents hazardous pressure levels

Find out more

All testing is conducted at UKAS-accredited laboratories and certified by the UK Vehicle Certification Agency (VCA).

Design Features

Fire Containment Systems

Triple-Layer Construction

Powder-coated sheet steel exterior for durability and chemical resistance
Double-walled internal chamber with TS50-grade insulation
Built-in spill containment bund for electrolyte capture
Reinforced structural frame designed to maintain integrity under extreme heat

Provides over 24 hours of fire resistance, containing heat and combustion products throughout the burn
Thermo-expanding seals that close ventilation gaps when exposed to fire
Controlled venting system that safely manages gas release during an incident

Have a custom requirement? Get in touch

How it works

Thermal runaway generates extreme heat, rapidly expanding gases, projectiles and flames. Battery Safe containers are engineered to manage each of these challenges:

Gas management and deflagration venting prevents pressure build-up

Thermo-expanding seals activate under high temperatures

Triple-layer steel and insulation structure absorbs and contains heat

Intumescent channels expand rapidly suppressing any flame escape.

Specifications

Maximum Capacity

20kWh battery energy

Internal Volume

400 litres

Maximum Battery Weight

Up to 421kg

Maximum Gross Weight

766kg

Multi-Unit Set Up

Stackable up to 3 units

Logistics

UK pallet footprint for easy transport

Safe storage and transport of lithium batteries

Our solutions are designed to support the safe storage and compliant transport of lithium batteries across a wide range of operational, commercial and industrial environments. Each unit is engineered to manage the risks associated with damaged, defective or end-of-life lithium batteries while meeting relevant transport and safety regulations.

Bottom Lift Test

Top Lift Test

Insulation Board

Stack Test

Drop Test Orientation

Thermal Runaway Test

Contact our team to learn more

UN compliance for transport of lithium batteries

This solution is for storage and transport of lithium batteries, providing organisations with a reliable way to manage damaged, defective and end-of-life batteries in line with recognised UN dangerous goods regulations for transportation.
